day 22 of learning programming from scratch. (continued from where i left off). understanding branch datapath operations. how datapath segment handle branches. using prev datapath elements to make one single datapath. multiplexor, control signal to work with multiple inputs
6
15
284
What's this? Another #Craptastic2024 entry? Surely I'm not just testing the new multiplexor code, right? A multiplexor in a 4K game? Am I bonkers? (Yes)
3
3
32
Phew only 3 levels to go. Level 13 has alot of moving parts, had to tweak the multiplexor. (sorry it's a camera pic)
0
3
11
*** SEGA GENESIS S.O.T.A Level 1 Progress ***. Much news on SOTAs development and some sneak peaks !!. Added a sprite multiplexor to the engine, mainly for weather effects as I was running out of sprites when a large number of sprites was needed - like the rain part of stage 1
18
51
200
Just found the code to my first "sortless" multiplexor for the C64 - the thing that piqued Dave Collier's interest when I first visited Ocean, and ultimately led me to join the company.
5
7
79
Today in #Commodore64 land, I am mostly thinking about improving the general purpose multiplexor.
4
2
15
Reparacion: .HitBit 75P. Sintoma: Cursor inferior o Joystick inferior pisado. Se desconecta clema del teclado: Sigue el síntoma (es el Joystick).Se revisan los 2 port del Joy:Correcto. Causa de la avería: El Multiplexor de entrada de señal Joystick (74LS157P)cortocircuitado.
3
6
17
Recovered source code for Imagine's C64 conversion of Konami's Typhoon, written by Zach Townsend. This one surprised me as it used my old sortless multiplexor.
4
2
67
wow it seems ChatGPT really can do anything. I got it to write me a sprite multiplexor in 6502 assembler. #c64 #commodore64
0
0
1
he visto esto y se me ha cerrado el estomago pensando que he tenido en cuenta la frecuencia de la señal en el multiplexor. Luego he recordado que estoy usando señales DC.
0
0
0
Ere now, if ya wanna simulate the ol' multiplexor 74HC4067 usin’ that proteus circuitss simulation software, it’s gonna throw ya an error if ya go with the 74HC4067 model, innit? ahahahah, To get it workin’, ya gotta use the 74154 model instead. that’ll do the trick!
0
0
0
Had a spare few minutes so I built a multiplexor that switches between two 4-bit gates. Guess I need to build one that switches between four 16-bit gates now 🥲
1
0
2
Busy working on the multiplexor. Gapping at the moment, but stability comes first, then looking to reduce the gaps down between the rows. Not easy on a C64. Score and invaders can still be moved up more pixels at the top of the screen. #c64vcsinvaders @rwxdesigns #c64reposts
2
8
31
