Done and dusted! ATmega32u4 Neopixel board for a Lighting fixture. PCB done by @JLCPCB.#PCB #embedded #Kicad

ESP32-C6-WROOM board for motor control. It has been designed and manufactured. Now it is time to test it. Thank you @kicad_pcb and @PCBWayOfficial .#PCB #Embedded #ESP32

RT @WorldAthletics: Male Athlete of the Year nominee ✨. Retweet to vote for Kelvin Kiptum 🇰🇪 in the #AthleticsAwards. .

RT @WorldAthletics: Female Athlete of the Year nominee ✨. Retweet to vote for Faith Kipyegon 🇰🇪 in the #AthleticsAwards. .

When you are that good in hardware design, results such as this is expected. A beautiful PCB designed and manufactured. The client is delighted. Design done courtesy of @kicad_pcb and manufacturing by @PCBWayOfficial

RT @kahome_steve: Thread🧵. Every investor should understand how to build a portfolio. Here is everything you need to know about asset allo….

Nothing beats the joy of doing a design and upon testing everything works flawlessly. This one has ESP32, BME680 sensor, Ethernet, Proximity sensor and Power metering. Design done with @kicad_pcb and manufactured by @JLCPCB

Another wonderful design just completed courtesy of @kicad_pcb . Features are: STM32 microcontroller, 3-Axis Accelerometer, Proximity and Ambient Light Sensor, OLED display and buzzer. Looking forward to positive feedback from client once the board is manufactured and tested.

Here is a wonderful project that is ideal for monitoring plants. It has ESP32-C3, BME280 for measuring humidity, pressure and temperature and LDR for ambient light sensing and inbuilt parasitic capacitive moisture sensing. Design done courtesy of @kicad_pcb

It's been a while. Here is an amazing design, courtesy of @kicad_pcb software. The MCU is MDBT50Q. Other features include 16-bit ADC ADS115, microSD socket, LiPo battery charging and Micro B USB. My client was delighted by the design and order has been placed for production.

I've had the pleasure of designing this Bluetooth Display Board for a German based client, courtesy of @kicad_pcb . Features include: MDBT50Q-1MV2 BLE Module, NFC,USB-C, LiPo battery and 4.2 inch display. Can't wait to have the board manufactured and tested.

Here is a MIDI Controlled Solenoid Drum Machine Board design courtesy of @kicad_pcb . A big thank you to the @kicad_pcb team for giving us such a superb and robust design software free of charge.

I did this design courtesy of @kicad_pcb a few weeks ago. It has ESP32, NEO-6M GPS, MicroSD slot among other functions. @PCBWayOfficial handled the manufacturing and the quality of the pcbs is really good. Upon testing, all works well. My client is happy, and so I'm I.

Just finished doing this awesome design using @kicad_pcb. It has ESP32-D0WD-V3, Camera and Microphone. Pcb manufacturing will be done by @PCBWayOfficial. Kindly visit this link to check out my portfolio. Or via email: gideon.mugo07@gmail.com

An ESP32 based board for a client in the Netherlands. It will be used to control green walls with vegetation. Kindly visit this link to check out my portfolio. Or via email: gideon.mugo07@gmail.com.#design #PCBlayout #esp32 #kicad #electronics #IoT

For professional PCB designs and to check out my portfolio kindly reach out to me via this link: #design #pcblayout #raspberry #computemodule4 #pcb #kicad #electronics #iot #wireless #electricalengineering #engineering.

I've just finished designing this board for another client in the US. It's a Raspberry Pi Compute Module 4 board. Some of the features of this board include: Ethernet, PoE, two USB2.0 USB-A, micro SD and 7v to 35v input. Can't wait for this board to be manufactured and tested.

RT @skndungu1: KiCad Master Class Prt6 Simple DC Power supply design (1) Schematic via @YouTube.

Another ESP32 based IoT board for a client in Sweden. The board uses 85-230V mains voltage and controls two AC devices via the two 10A relays on board. To check more on my work, kindly visit my page: #design #esp32 #pcb #kicad #iot
