Voice and data transmission between crew and radios is carried out by Larimart's UIS-379/D digital intercom system, which is also installed on the B2 Centauro. The crews have an SC-824 graphic operating unit, an intuitive graphical human-machine interface with a convenient knob.

In addition to the VQ1, the C2 Ariete also has an L3Harris AN/PRC-152A handheld radio installed in the vehicle, mainly for SATCOM. For transmission inside and outside, new EVO-A-TACSAT low-profile UHF antenna is installed.

On early C2 Ariete PT-prototypes the old SINCGARS III frequency hopping radio system was still retained, identifiable by the distinctive Italian AT-2730/AT-2731 antennas.

The VQ1 radio set operates between HF/HF/UHF (2 MHz to 2000 GHz), and for C2 Ariete application, it includes 2 VHF and 2 UHF channels. It can be seen that its appearance is equipped with 2 sets of EVO-A-V-WHIP whip antennas and 2 sets of EVO-A-UTAC low-profile antennas.

The C2 Ariete is equipped with the SWave VQ1 (Vehicular Quad-channel Type1) software defined radio developed by Leonardo Electronics to replace the SINCGARS (RT-1702C) radio. The 4-channel pack can replace four legacy transceivers while reducing the space occupied on the vehicle.

CIO (Consorzio Iveco-Oto Melara) delivered the first production C2 Ariete main battle tank to the Italian Army two days ago. The following thread is to discuss its new generation of communication equipment configuration in Italian Army AFVs.

The Poland Army's newest M1A2 SEPv3 tank, note two RF-3144TB rigid antenna, which is suitable for the AN/PRC-158 Falcon IV multi-channel SDR. For the JETDS designation, the vehicular version of the PRC-158 is the AN/VRC-124 or -125, depending on the single or dual mounted system.

M1A2 SEPv3 Abrams pilot vehicle is equipped with AN/VLQ-12(V)3 Counter Remote-Controlled Electronic Warfare (CREW) Duke V3 system. Note the Duke V3 Remote Control Unit (RCU) next to the loader's panel.

AN/VRC-89G radio set with RT-1523G (ASIP) transceivers in the M1A2 SEPv3 Abrams turret

@DRatka1 @AllAboutM1A.

This thread is a correction to a previous post about export Abrams radio. I mistakenly put the SINCGARS used by the Saudi LAV of the Saudi Arabian National Guard (SANG) on the M1A2S of the Royal Saudi Land Forces (RSLF).

In addition to the Thermal Management System (TMS), the M1A2S can be identified visually by its new VHF3088VM rigid antennas.

The new M1A2S delivered to Saudi Arabia since 2006 are further upgraded with Racal's Panther-V Enhanced Data Radio (EDR), an improved version of the company's Panther-2000V with built-in GPS, which can transmit data to the Inter-vehicular Information System (IVIS) of M1A2S.

In addition to the Saudi M1A2 (sorry no good photos), Racal's (now Thales UK) VRQ-316 Jaguar-V vehicle-mounted radio set, is also selected by Oman's Challenger 2 and Kuwait's M-84AB, was the first generation of frequency-hopping radio developed by the Racal company.

Not all Abrams models are equipped with the US-made radios, and the Saudi variant is a special case. The 315 M1A2 (KSA) tanks ordered by the Royal Saudi Land Forces were all equipped with the British Racal Jaguar-V frequency-hopping radio and new antennas visible.

Elbit's fourth-generation 105mm APFSDS-T cartridge M428 used by Argentinian TAM battle tank

@VinodDX9 @SupratikSaumya @T_90AK @AndreiBtvt.

The interior views of Indian upgraded T-72M1 CI-Ajeya tank. Note that the old TKN-3 sight has been replaced with new Commander's Thermal Imager cum Day Sight (CTI) MK-II. Another interesting fact is that Tadiran's CNR900M frequency-hopping radio in place of the Soviet-era R-173.

Taiwan's army displayed the firepower of the first batch of M1A2T Abrams tanks made by @GD_LandSystems. M1A2T is a special model with some analog vetronics, and the turret structure/sights are equivalent to digital SEPv2. It can be identified from the ACPS at the turret bustle
