Supercritical airfoils suggest speed of around 800-900km/h, but every report/video of them being shoot down is at 600km/h. Did they misscalculate speed by 300km/h or missile goes 900km/h in specific scenarios that would compensate for 600km/h average cruise?
One of the Two Ukrainian Flamingo FP-5βs Cruise Missiles that were Crowdfunded through a Czech civilian fundraiser initiative.
0
0
2
I overlooked cooling. Small but powerful force feed air system should be the way to go. It has to allow engine made for 4kW work at 8-12kW. ESC will transfer heat to metal wing surfaces.
0
0
0
Torque from propeller is so big that it bends/vibrates frame at high power. Reinforcement should help
1
0
2
Today cat knocked osciloscope off the lab table so he could sleep on it.
0
0
2
Tests show that whole chain has efficiency of around 3 g/W DJI Mavic 3 has 7g/W. My requirement is 10g/W Theres a lot of space for chain upgrades - balancing, connections, prop, engine. Engine and connections seem to be waste a lot of power.
0
0
1
Hub broke and propeller flew upwards, hit the celling and was hovering there for 5 seconds. Looks like efficiency is quite good lol
0
0
0
It turns out that solver was wrong about high speed propellers. Thank you nasa for this public research β₯οΈ
0
0
2
It turns out that solver was wrong about high speed propellers. Thank you nasa for this public research β₯οΈ
0
0
3
I wish so much that i could use them, but they are 200$ each, horrible to program for and cost fortune, have to rely on external SOM instead. PCB design would be devastating also
0
0
0
I will be likely going away from lift engine to gimbaled props in final version. prototype will be aero stable and has a flight time goal of 45 minutes in hover and ground speed goal of 170km/h. single FPV VTX and analog cam + LFLDCM, so range will be something like 2 km.
0
0
1
Prototype model is nearly finished, only smaller cosmetic things are left. Real thing is under construction, i hope soon i will be able to show finished parts of it. Now there will be a lot of work related to electronics and software.
2
0
1
Quite a shame that every RFSoC costs as much as a car.
Introducing Zynq #RFSoC DFE, a breakthrough class of device for mass #5Gradio deployments. Meet evolving #5G standards with adaptable hardware flexibility and a hardened radio digital front-end for performance, power, and cost effectiveness. Learn more: https://t.co/Nuel9ZE4ef
0
0
1
why does every single 3D physics library requires both cmake and build from source
0
0
0
It's basicly titan submarine but flying
true - A Russian Pantsir took out a Flamingo ! Russians say the electronics looks a bit cheap and improvised...
