Most dashcams record. #RoadInspect understands. A triple-camera system for next-gen vehicle vision with wide outdoor coverage, IR-enabled driver monitoring, and low-latency #GMSL imaging. It's not just a dashcam – it's a platform for #EdgeAI in #mobility🚘 #dashcam

rc_visard NG by @roboceptionGmbH : Jetson Orin, stereo vision & passive cooling in one compact housing – no fan, no host PC. We supported with high-speed multilayer #PCBDesign (signal integrity, #EMC , thermal layout) and scalable electronics production💪 #RobotVision

Did you know? USB-C isn’t just for charging – it can detect water in the port and disable power to prevent shorts or corrosion. It uses CC pins + smart firmware. Rarely well-implemented, but we’ve built it deep into #Helium for real-world reliability. #USBC #WaterDetect

Rugged ≠ just a sealed box. Many “great” systems fail in the field due to small physical issues: vibration, dust, heat, cable stress. With #Helium, we designed for the real world – IP67, screw-lock connectors, flexible cooling. Built for the edge!

To evaluate #BGASSD technology, we tested an adapter prototype in M.2. Measuring just 16 × 20 × 2 mm, it removes connectors for more durability, simplifies production, and improves energy efficiency for longer battery life. A compact storage solution where every mm counts💪

Our PCB Arts Tech Meet-up is back – more community-driven than ever🎉 Network, share insights & pitch your own project in a 5-min slot! Let’s shape the future of embedded systems together🚀 Participation is free, but spots are limited: https://t.co/c2MxjckU9d #Networking #MEETUP

Get your tickets for free:

Calling Tech Enthusiasts Attending Embedded World 2024, join us at the PCB Arts Tech Meetup on 10.04.2024 in Nuremberg. It will be a good networking event from engineers for engineers. See you there!

4x FPD Link III 2,5Gbit/s per Link, will be available soon on our EdgeKit. But not just the hardware, also the drivers for FPD Link and the @AlliedVisionTec (avt_csi2) drivers, with all the higher level Frameworks (VimbaX) will come pre-installed on the lastest #NVIDIA JetPack.

We´ve uploaded the design files of our FPD Link serializer board for the Raspberry Pi global shutter camera module. This is still a work in progress, but verification should be finished soon 🙌 https://t.co/0iueLn3a8d

Exciting to discover the capabilities of FPD Link -transmitting up to 4,16 GBit/s of data, supporting I2C communication, GPIO's, powering devices up to 10 watts over a single coax cable and that with cables up to 15m long.

In our modular edge AI computer „EdgeKit“, we’re always working on new interfaces to provide more possibilites for solution integrators. We’ve right now bring up with FPD Link and testing it with the @AlliedVisionTec Camera. Now Linux Device Tree adaption is the next step.

You are at Embedded World and want to exchange ideas with other tech people and talk about your own projects? Come to the PCB Arts Meetup in Nuremberg on 15.03 https://t.co/MDmQ4gFWn0

After many requests for reworking with the Vapor Phase One we’ve developed and launched a new desoldering tool! We were able to desolder this GPU-BGA really easily with the desoldering kit. Maybe we should try to solder this chip back into the iMac video card again.

Simulation results can look beautiful 😊 What you can see here is the PDN analysis of a power supply trace simulated with the awesome open-source tool Elmer-FEM. We used a coupled heat solver to calculate the temperature rise of the trace.

This happens when you enter "PCB Arts as pencil drawing" into DALL-E 2 and throw the image directly onto the laser. Optimizable.. 😇

We rescued this little 10W laser from disposal and made it safe for use in our office. The safety equipment is about 5x as expensive as the laser itself. Better safe than sorry 😇

Before always doing custom engineering, we developed a modular EdgeAI system based on NVIDIA's Jetsons. 🥹 The whole thing online configurable - of course with web rendering. Check out the beta: https://t.co/RuP8UeT0bP

How many layers do you need? - "Two" Okay twelve it is

We just opened our booth at the embedded world exhibition! Visit us for a nice chat and a snack :)
